Display large, bright images for optimal viewability with this reliable laser projector.
Project vivid, colorful, impactful images up to 500″ with EB-L200F Standard-Throw laser projector. This 4,500-lumen*1, Full HD* projector delivers bright, easy-to-read images from nearly anywhere in the room, and it offers built-in split screen*1 to create an even more immersive and engaging experience. Designed with flexibility and convenience in mind, the EB-L200F provides built-in wireless and Miracast® support and a long-lasting virtually maintenance-free 20,000-hour laser light source with no lamps to replace*7.
Bright and Compact
Using Epson’s very own original designed fixed phosphor unit, coupled with the innovative optimized design, the L200 series is now more compact yet images remain bright and sharp. Thanks to the new heatsink design, the L200 series has efficient heat conductivity, resulting in improved heat resistance, all while delivering high-quality vivid images.
Large Images
With a wide projection screen size of up to 500 inches*, you enjoy big image projection for good visibility.
Bright Image Quality
With bright images of up to 4,500lm, it will allow clear image even in ambient light conditions from fluorescent lamps or sunlight from windows.
Split Screen Function
This 4,500-lumen*1, Full HD* projector delivers bright, easy-to-read images from nearly anywhere in the room with the ability to do 4 split screens to create an even more engaging experience.
Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system
Specifications of Main Parts:
LCD:Size: 0.62” (C2Fine)
Resolution: Full HD (1080p)*Lightsource:Type: Laser Diode
Life (Normal / Quiet / Extended): 20,000 / 20,000 / 30,000 hrsProjection Lens:Type: Optical Zoom (Manual) / Focus (Manual)
F-Number: 1.49 – 1.77
Focal Length: 18.2 – 29.2mm
Zoom Ratio: 1.0 – 1.62 (Optical Zoom)
Throw Ratio: 1.33 – 2.16
Connectivity:
Network:Wireless:
Built-in x 1
Optional x 1 (using optional ELPAP11)
Wired Lan:
RJ45 x 1 (100Mbps)Analog Input:D-Sub 15Pin: 2 (RGB)
Composite RCA x 1 (Yellow)Digital Input:HDMI: 2 (HDCP 2.2)Analog Output Terminal:D-Sub 15Pin: 1 (Black)Audio Input:RCA: 1 (White, Red)
Stereo Mini Jack: 2Audio Output:Stereo Mini Jack: 1Control I/O:RS-232C: D-Sub 9pin x 1Others:USB Type A: 1 (for Saving and Reading Data via USB, Firmware Update, Copy OSD Settings, Document Camera)
USB Type B: 1 (for Firmware Update, Copy OSD Settings)
Mic I/O: Stereo Mini x 1
Contrast Ratio:
Contrast Ratio:Over 2,500,000 : 1
Screen Size (Projected Distance):
Standard Size:60” screen @ 172cmZoom : Wide:40” to 500” screen (114 – 1,461cm)
Geometric Correction:
Vertical/Horizontal Keystone:±30° / ±30°Quick Corner:Yes (Manual
Operating Temperature:
Single Use:0 – 2,286 m (0 – 7,500 ft): 0 °C – 40 °C [32 °F – 104 °F ] ; 20% to 80% Humidity, No Condensation
Over 2,286 m (7,500 ft): 0 – 35 °C [32 °F – 95 °F] ; 20%-80% Humidity, No CondensationMulti-projection Use:0 – 2,286 m (0 – 7,500 ft): 0 °C – 35 °C [32 °F – 95 °F ; 20% to 80% Humidity, No Condensation Over 2,286 m (7,500 ft): 0 – 30 °C [32 °F – 86 °F] ; 20%-80% Humidity, No Condensation
Operating Altitude:
Operating Altitude:Over 1,500 m / 4,921 ft, with High Altitude Mode: 0 – 3,048 m (0 – 10,000 ft)
Start-Up Period:
Start-Up Period:Less than 8 seconds, Warm-up Period: 30 seconds
Quick Start-Up: Less than 5 seconds (Display)
Cool Down Period:
Cool Down Period:Instant Off
Internal Speaker(s):
Sound Output:16W Monoaural
Direct Power On/Off:
Direct Power On/Off:Yes
Weight:
Weight:Approx. 4.1kg
Air Filter:
Type:Electrostatic FilterMaintenance Cycle:20,000 hours*5
Fan Noise:
Fan Noise (Normal / Eco):36dB / 27dB
Dimension Excluding Feet:
Dimension Excluding Feet (D x W x H):299 x 325 x 90 mm
Optional Wireless & Built In Lan Specifications:
Supported Speed for each Mode:Infrastructure: IEEE 802.11b (2.4GHz): 11Mbps*3, IEEE 802.11g (2.4GHz): 54Mbps*3 IEEE 802.11n (2.4GHz): 72.2Mbps*3, IEEE 802.11a (5GHz): 54Mbps*3, IEEE 802.11n (5GHz): 150Mbps*3, IEEE 802.11ac (5GHz): 325Mbps*3
Access Point (Wi-Fi Direct): IEEE 802.11g (2.4GHz): 54Mbps*3, IEEE 802.11n (2.4GHz): 72.2Mbps*3, IEEE 802.11a (5GHz): 54Mbps*3, IEEE 802.11n (5GHz): 150Mbps*3, IEEE 802.11ac (5GHz): 325Mbps*3Wireless LAN Security:Infrastructure: OPEN, WPA2 / WPA3-PSK, WPA2 / WPA3-EAP
Supported EAP Type: PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
Access Point (Wi-Fi Direct): WPA2-PSK (AES)Supported Mode:Infrastructure, Access Point (Wi-Fi Direct)
Brightness:
White Light Output (Normal / Eco):4,500lm / 3,150lmColour Light Output:4,500lm
Image:
Noise Reduction:YesSuper-Resolution:YesDetail Enhancement:Yes
Power Consumption (220-240V):
Lamp On (Normal/Eco):254W / 193WStandby:2.0W / 0.5W (Network On / Off)
Projectors Facets:
Resolution, Projectors Facets:FullHDContrast Ratio, Projectors Facets:Over 2,500,000:1Brightness Range Lumens, Projectors Facets:4001Features, Projectors Facets:Wifi
Screen Mirroring
Quick CornerLaser / Lamp, Projectors Facets:Laser
What’s In The Box:
Power Cable: 1.8m x 1
HDMI Cable (1.8m)
Remote Control with 2x AA Battery
